How to consume Dynamics AX Product Images in PowerApps

Step 1: Create a sample data entity as shown below. It uses EcoResProductImage table which holds the image container of the items.

1

Step 2: Check the odata feed in the browser. You can see the Base64 images are exposed in “MediumSize” field as shown below.

2

Step 3: Create a sample PowerApps application and add a gallery. Assign the data source to the gallery.


Step 4: Assigning the “MediumSize” to the image will not shows up the image in PowerApp. So add the below code in the image source to specify the Base64.


3
